Thermisch Module
Beeldsensor: Vanadiumoxide ongekoelde focal plane arrays
Resolutie: 640 x 512
Pixelafstand: 12 μm
NETD: ≤ 25 mK (@25° C, F# = 1,0)
Brandpuntsafstand: 5,1 mm
IFOV: 2,35 mrad
Diafragma: F1.0
Gezichtsveld: 90° × 67,2° (H × V)
Digitale zoom: x2, x4
Minimale scherpstelafstand: 1 m
Optisch Module
Beeldsensor: 1/2,7" progressieve scan CMOS
Resolutie: 2688 × 1520
Minimale verlichting: Kleur: 0,05 Lux @ (F1.6, AGC aan), Z/W: 0,01 Lux @ (F1.6, AGC aan)
Gezichtsveld: 114,6° × 63,8° (H × V)
Brandpuntsafstand: 2,27 mm
WDR: 120 dB
Beeld Effect
Beeld-in-beeld: Toon gedeeltelijk beeld van het thermische kanaal op het volledige scherm van het optische kanaal
Doelkleuratie: Ja, ondersteund in witheet en zwartheet modus
EIS: Thermisch kanaal ondersteunt EIS, exclusief met alle slimme functies
Verlichter
IR afstand: Tot 30 m
IR intensiteit en hoek: Automatisch aangepast
Slimme Functie
VCA: 4 VCA-regeltypes (lijnovergang, inbraak, gebied binnenkomen, gebied verlaten), tot 8 VCA-regels
Temperatuurmeting: 3 types temperatuurmeetregels, 21 regels (10 punten, 10 gebieden, 1 lijn)
Temperatuurbereik: -20°C tot 650°C
Temperatuurnauwkeurigheid: Max. (± 2°C, ± 2%)
Branddetectie: Dynamische branddetectie, tot 10 brandpunten detecteerbaar
Rookdetectie: Ondersteunt rookdetectie op optisch kanaal
Interface
Alarm Ingang: 2-kanalen (0 tot 5 VDC)
Alarm Uitgang: 2 relaisuitgangen, alarmreacties configureerbaar
Alarmactie: SD-kaart opnemen / relaisuitgang / slimme opname / FTP upload / e-mail koppeling
Audio Ingang: Mic in / lijn in interface. Lijninvoer: 2 tot 2,4V[p-p], uitgangsimpedantie: 1 kΩ ± 10%
Audio Uitgang: Lineair niveau; impedantie: 600 Ω
Communicatie Interface
1 × RJ45 10 M/100 M zelfaanpassende Ethernet interface
1 × RS-485 interface (half duplex)
Netwerk
Hoofdstream
Thermisch: 25 fps (1280 × 720, 704 × 576, 640 × 512, 352 × 288)
Optisch:
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Substream
Thermisch: 25 fps (704 × 576, 640 × 512, 384 × 288)
Optisch:
50 Hz: 25 fps (704 × 576, 352 × 288)
60 Hz: 30 fps (704 × 480, 352 × 240)
Video compressie
H.265 / H.264 / MJPEG, H.265+ / H.264+ codering met Baseline / Main / High Profile
Audio compressie
G.711u / G.711a / G.722.1 / MP2L2 / G.726 / PCM
Protocollen
IPv4 / IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Gelijktijdige live weergave
Tot 20
Gebruiker / Host niveaus
Tot 32 gebruikers, 3 niveaus: Administrator, Operator, Gebruiker
Beveiligingsmaatregelen
Gebruikersauthenticatie (ID en wachtwoord), MAC-adresbinding, HTTPS-encryptie, IEEE 802.1x toegangscontrole, IP-adresfiltering
Integratie
SD Geheugenkaart
Ingebouwde Micro SD-kaartslot, ondersteunt Micro SD/SDHC/SDXC kaarten (tot 256 GB), ondersteunt handmatige / alarmopname
Applicatie Programmatuur
Ondersteuning ISAPI, HIKVISION SDK en derde-partij beheersplatform
Client
iVMS-4200
Webbrowser
Google Chrome 57+, Mozilla Firefox 52+, Internet Explorer 10+, Mac Safari 12+
Algemeen
Menu Taal
33 talen waaronder Engels, Russisch, Ests, Bulgaars, Hongaars, Grieks, Duits, Italiaans, Tsjechisch, Slowaaks, Frans, Pools, Nederlands, Portugees, Spaans, Roemeens, Deens, Zweeds, Noors, Fins, Kroatisch, Sloveens, Servisch, Turks, Koreaans, Traditioneel Chinees, Thai, Vietnamees, Japans, Lets, Litouws, Portugees (Brazilië), Oekraïens
Voeding
100 tot 240 VAC, PoE (802.3af)
Vermogensverbruik
Maximaal 11 W
Werktemperatuur / Vochtigheid
-40°C tot 60°C, ≤ 95% zonder condensatie
Beschermingsniveau
IP68 standaard, TVS 6000V bliksembeveiliging, overspanningsbeveiliging, spanningspiekenbeveiliging
Afmetingen
290,7 mm × 177,5 mm × 152,0 mm
Gewicht
Ongeveer 6,5 kg
Goedkeuringen
EMC: CE-EMC (EN 55032:2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN50130-4:2011+A1:2014); RCM (AS/NZS CISPR 32:2015); IC (ICES-003: Issue 7)
Veiligheid: CB: IEC 62368-1:2014+A11; CE-LVD: EN 62368-1:2014/A11:2017
Bescherming: IP68: IEC 60529-2013
Explosiebeveiliging:
ATEX: II 2 G Ex db IIC T6 Gb / II 2 D Ex tb IIIC T80°C Db
IECEx: Ex db IIC T6 Gb / Ex tb IIIC T80°C Db
Anti-corrosie bescherming: NEMA 4X (NEMA 250-2018), C5
